Products

7 results
View:
Compare

Categories

Filters

2SS-33A-R1 2SS-33A-R1
8-Port multibeam antenna ,8x 3100-4200 MHz , 4x 33° HPBW, 1x RET
2SS-33A-R1
  • Product Type: Multibeam antenna
  • Horizontal Beamwidth: 33°
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, high band: 8
SpecificationsSpecs
2SS-33A-R1
  • Product Type: Multibeam antenna
  • Horizontal Beamwidth: 33°
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, high band: 8
8P-8M-A4 8P-8M-A4
8P-8M-A4
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 3300 – 5000 MHz
  • Horizontal Beamwidth: 45°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: 458 – 498 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 8
  • RF Connector Quantity, high band: 8
8P-8M-A4
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 3300 – 5000 MHz
  • Horizontal Beamwidth: 45°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: 458 – 498 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 8
  • RF Connector Quantity, high band: 8
FF2HH-6533C-R5 FF2HH-6533C-R5
12-Port Sector/multibeam antenna, 4x 617–894 MHz 65° HPBW and 8x 1695–2360 MHz 4x 33° HPBW, 5x RET
FF2HH-6533C-R5
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 33° | 65°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 12
  • RF Connector Quantity, high band: 8
  • RF Connector Quantity, low band: 4
SpecificationsSpecs
FF2HH-6533C-R5
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 33° | 65°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 12
  • RF Connector Quantity, high band: 8
  • RF Connector Quantity, low band: 4
R2VV-6533B-R5 R2VV-6533B-R5
10-port sector/multi beam antenna, 2x 698-960 sector and 8x 1710-2690 multi beam, 65° sector and 33° 4x multi beam, 5x RET with tilt indicators
R2VV-6533B-R5
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 33° | 65°
  • Length Size: 2.0 m (6 ft)
  • Width/Diameter: 306 – 353 mm
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 10
  • RF Connector Quantity, high band: 8
  • RF Connector Quantity, low band: 2
SpecificationsSpecs
R2VV-6533B-R5
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 33° | 65°
  • Length Size: 2.0 m (6 ft)
  • Width/Diameter: 306 – 353 mm
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 10
  • RF Connector Quantity, high band: 8
  • RF Connector Quantity, low band: 2
R2VV-6533C-R5-V3 R2VV-6533C-R5-V3
10-port sector/multibeam antenna, 2x 694-960 and 8x 1695–2690 MHz, 65°|4x 33° HPBW, 5x RET
R2VV-6533C-R5-V3
  • Product Type: Multibeam antenna
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 10
  • RF Connector Quantity, high band: 8
  • RF Connector Quantity, low band: 2
SpecificationsSpecs
R2VV-6533C-R5-V3
  • Product Type: Multibeam antenna
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 10
  • RF Connector Quantity, high band: 8
  • RF Connector Quantity, low band: 2
RR2VV-6533D-R6 RR2VV-6533D-R6
12-port sector/multibeam antenna, 4x 698–960 MHz 65° HPBW and 8x 1710–2690 MHz 4x 33° HPBW, 6x RET
RR2VV-6533D-R6
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 33° | 65°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: 458 – 498 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 12
  • RF Connector Quantity, high band: 8
  • RF Connector Quantity, low band: 4
SpecificationsSpecs
RR2VV-6533D-R6
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 33° | 65°
  • Length Size: 2.5 m (8 ft)
  • Width/Diameter: 458 – 498 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 12
  • RF Connector Quantity, high band: 8
  • RF Connector Quantity, low band: 4
RRVV2VV-6533B-R8 RRVV2VV-6533B-R8
16-port sector/multibeam antenna 4x 694–960 MHz, 4x 1695-2690 MHz 65° HPBW and 8x 1710–2690 MHz 2x 2-Beam 33°HPBW, 8x RET
RRVV2VV-6533B-R8
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 33° | 65°
  • Length Size: 2.0 m (6 ft)
  • Width/Diameter: 458 – 498 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 16
  • RF Connector Quantity, high band: 12
  • RF Connector Quantity, low band: 4
SpecificationsSpecs
RRVV2VV-6533B-R8
  • Product Type: Multibeam antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 33° | 65°
  • Length Size: 2.0 m (6 ft)
  • Width/Diameter: 458 – 498 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 16
  • RF Connector Quantity, high band: 12
  • RF Connector Quantity, low band: 4
