Meet the new small cell antenna platform that bridges the gap between now and next. CommScope advanced outdoor small cell antennas are uniquely designed to deliver everything operators need to solve their toughest densification and 5G challenges.

Speed of deployment iconFaster Deployment
Compact, concealed and capable, these small cell antennas speed permitting, install easily and reduce re-zoning during upgrades.
Small Cell iconExpanded Coverage

Depending on model and configuration, one compact antenna can support legacy low- and mid-bands, 3.5 GHz applications, 4x MIMO and carrier aggregation.

customizable-iconQuickly Customizable

Factory-configurable patterns, port counts, frequency bands and tilts provide a best-fit solution without compromising deployment schedules.


Now, one innovative small cell antenna portfolio enables you to densify your network and add the high-speed capacity and quality of service your users expect. Now and next.

Products

of 54 results found
View:
Compare

Categories

Filters

VV-360A-F VV-360A-F
VV-360A-F
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 360 °
  • Length Size: 2.0 m (6 ft)
  • Width/Diameter: ≤ 200 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 4
  • RF Connector Quantity, high band: 4
VV-360A-F
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 360 °
  • Length Size: 2.0 m (6 ft)
  • Width/Diameter: ≤ 200 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 4
  • RF Connector Quantity, high band: 4
VV-360S-F VV-360S-F
VV-360S-F
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 360 °
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: ≤ 200 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 4
  • RF Connector Quantity, high band: 4
VV-360S-F
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 360 °
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: ≤ 200 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 4
  • RF Connector Quantity, high band: 4
VV-65T-F-V3 VV-65T-F-V3
4-port small cell antenna, 4x 1695–2690 MHz, 65° HPBW, fixed electrical tilt
VV-65T-F-V3
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: <0.7 m (2 ft)
  • Width/Diameter: ≤ 200 mm
  • RF Connector Interface: NEX10 Female
  • RF Connector Quantity, total: 4
  • RF Connector Quantity, mid band: 4
SpecificationsSpecs
VV-65T-F-V3
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: <0.7 m (2 ft)
  • Width/Diameter: ≤ 200 mm
  • RF Connector Interface: NEX10 Female
  • RF Connector Quantity, total: 4
  • RF Connector Quantity, mid band: 4
VVP-360S-F VVP-360S-F
VVP-360S-F
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 5000 – 6000 MHz
  • Horizontal Beamwidth: 360 °
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: ≤ 200 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 6
  • RF Connector Quantity, high band: 6
VVP-360S-F
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 5000 – 6000 MHz
  • Horizontal Beamwidth: 360 °
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: ≤ 200 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 6
  • RF Connector Quantity, high band: 6
VVS4P-360S-F2 VVS4P-360S-F2
14-port small cell antenna, 4x 1695-2690, 8x 3100- 4200,2x 5150-5925 MHz, 360° Horizontal Beamwidth, fixed tilt.
VVS4P-360S-F2
  • Product Type: Small cell antenna
  • Horizontal Beamwidth: 360°
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 14
  • RF Connector Quantity, high band: 14
  • RF Connector Quantity, low band: 0
SpecificationsSpecs
VVS4P-360S-F2
  • Product Type: Small cell antenna
  • Horizontal Beamwidth: 360°
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 14
  • RF Connector Quantity, high band: 14
  • RF Connector Quantity, low band: 0
VVS4SSP-360S-F2 VVS4SSP-360S-F2
18-port small cell antenna, 4x 1695-2690, 8x 3100-4200,4x 3100-4200, 2x 5150-5925 MHz, 360° Horizontal Beamwidth, fixed tilt.
VVS4SSP-360S-F2
  • Product Type: Small cell antenna
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 18
  • RF Connector Quantity, high band: 18
  • RF Connector Quantity, low band: 0
SpecificationsSpecs
VVS4SSP-360S-F2
  • Product Type: Small cell antenna
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 18
  • RF Connector Quantity, high band: 18
  • RF Connector Quantity, low band: 0
VVSS-360S-F2 VVSS-360S-F2
8-port small cell antenna, 4x 1695-2690, 4x 3100-4200 MHz, 360° Horizontal Beamwidth, fixed tilt.
VVSS-360S-F2
  • Product Type: Small cell antenna
  • Horizontal Beamwidth: 360°
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 8
  • RF Connector Quantity, high band: 8
  • RF Connector Quantity, low band: 0
SpecificationsSpecs
VVSS-360S-F2
  • Product Type: Small cell antenna
  • Horizontal Beamwidth: 360°
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 8
  • RF Connector Quantity, high band: 8
  • RF Connector Quantity, low band: 0
VVSSP-180HS-F2 VVSSP-180HS-F2
10-port small cell antenna, 4x 1695–2690, 4x 3100-4200 MHz, 2x 5150-5925 MHz, heart shape pattern, fixed tilt.
VVSSP-180HS-F2
  • Product Type: Small cell antenna
  • Horizontal Beamwidth: 180°
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 10
  • RF Connector Quantity, high band: 10
  • RF Connector Quantity, low band: 0
SpecificationsSpecs
VVSSP-180HS-F2
  • Product Type: Small cell antenna
  • Horizontal Beamwidth: 180°
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 10
  • RF Connector Quantity, high band: 10
  • RF Connector Quantity, low band: 0
VVSSP-360S-D VVSSP-360S-D
10-port small cell antenna, 4x 1695–2690, 4x 3300-4200 and 2x 5150-5925 MHz. 360° Horizontal Beamwidth, fix tilt
VVSSP-360S-D
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz | 5000 – 6000 MHz
  • Horizontal Beamwidth: 360°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: 201 – 305 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 10
  • RF Connector Quantity, high band: 10
SpecificationsSpecs
VVSSP-360S-D
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz | 5000 – 6000 MHz
  • Horizontal Beamwidth: 360°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: 201 – 305 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 10
  • RF Connector Quantity, high band: 10
VVSSP-360S-F VVSSP-360S-F
10-port small cell antenna, 4x 1695-2690, 4x 3300-4000, 2x 5150-5925 MHz, 360° Horizontal Beamwidth, fixed tilt.
VVSSP-360S-F
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz | 5000 – 6000 MHz
  • Horizontal Beamwidth: 360°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: ≤ 200 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 10
  • RF Connector Quantity, high band: 10
  • RF Connector Quantity, low band: 0
SpecificationsSpecs
VVSSP-360S-F
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz | 5000 – 6000 MHz
  • Horizontal Beamwidth: 360°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: ≤ 200 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 10
  • RF Connector Quantity, high band: 10
  • RF Connector Quantity, low band: 0
VVSSP-360S-F-V2 VVSSP-360S-F-V2
VVSSP-360S-F-V2
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3300 – 5000 MHz | 5000 – 6000 MHz
  • Horizontal Beamwidth: 360 °
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: ≤ 200 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 10
  • RF Connector Quantity, high band: 10
VVSSP-360S-F-V2
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3300 – 5000 MHz | 5000 – 6000 MHz
  • Horizontal Beamwidth: 360 °
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: ≤ 200 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 10
  • RF Connector Quantity, high band: 10
VVSSP-360S-M VVSSP-360S-M
10-port small cell antenna, 4x 1695–2690, 4x 3400-3800 and 2x 5150-5925 MHz. 360° Horizontal Beamwidth, MANUAL ELECTRICAL TILT
VVSSP-360S-M
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz | 5000 – 6000 MHz
  • Horizontal Beamwidth: 360°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: 201 – 305 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 10
  • RF Connector Quantity, high band: 10
SpecificationsSpecs
VVSSP-360S-M
  • Product Type: Small cell antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz | 5000 – 6000 MHz
  • Horizontal Beamwidth: 360°
  • Length Size: 0.7 m (2 ft)
  • Width/Diameter: 201 – 305 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 10
  • RF Connector Quantity, high band: 10
