CommScope’s innovative tri-sector antennas are an ideal replacement for existing tri-sector solutions that cannot support new 4G/5G bands and configurations and new deployments involving hard-to-permit in-fill sites. The portfolio features a compact design for aesthetically sensitive areas and a stackable model for deployment on existing structures.

Video: Meet CommScope’s new tri‑sector antenna portfolio.

Flexible deployment iconFlexible deployment

Both antenna designs support concealment, rooftop and flagpole deployments with simplified and repeatable installation, and both enable 2T2R, 4T4R, 8T8R configurations.

Easy-permitting design iconEasy-permitting design

Clean and compact design presents a unified, low-visibility look that accelerates zoning and deployment. Although compact, antennas deliver high-performance tri-sector coverage and up to 72 ports.

Future-ready expansion iconFuture-ready expansion

Support for the full range of 4G and 5G bands—617–960 MHz, 1400–2700 MHz and 3.5 GHz—and rapid, repeatable deployment let you add capacity and new services as your needs evolve.

Products

of 13 results found
View:
Compare

Categories

Filters

3X-KKV4S4-65B-R15 3X-KKV4S4-65B-R15
60-port sector antenna, 12x 617-960MHz, 24x 1695-2690MHz 65° HPBW and 24x 3300-3800 MHz, 90° HPBW, 15x RET
3X-KKV4S4-65B-R15
  • Product Type: Tri-sector antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 65° | 90°
  • Length Size: 2.0 m (6 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 4.3-10 Female | M-LOC
  • RF Connector Quantity, total: 60
  • RF Connector Quantity, high band: 24
  • RF Connector Quantity, mid band: 24
  • RF Connector Quantity, low band: 12
SpecificationsSpecs
3X-KKV4S4-65B-R15
  • Product Type: Tri-sector antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 65° | 90°
  • Length Size: 2.0 m (6 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 4.3-10 Female | M-LOC
  • RF Connector Quantity, total: 60
  • RF Connector Quantity, high band: 24
  • RF Connector Quantity, mid band: 24
  • RF Connector Quantity, low band: 12
3X-KVV-65A-R6 3X-KVV-65A-R6
18-ports tri-sector antenna, 6x 617-960 and 12x 1695-2690 MHz, 65° HPBW, 6x RETs.
3X-KVV-65A-R6
  • Product Type: Tri-sector antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 1.3 m (4 ft)
  • Width/Diameter: 354 – 457 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 18
  • RF Connector Quantity, mid band: 12
  • RF Connector Quantity, low band: 6
SpecificationsSpecs
3X-KVV-65A-R6
  • Product Type: Tri-sector antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 1.3 m (4 ft)
  • Width/Diameter: 354 – 457 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 18
  • RF Connector Quantity, mid band: 12
  • RF Connector Quantity, low band: 6
3X-KVVS4-65B-R12 3X-KVVS4-65B-R12
42-port tri-sector antenna, 6x617-960, 12x1695-2690MHz, 65°HPBW, 24x3300-3800MHz Beamformer, 12x RET
3X-KVVS4-65B-R12
  • Product Type: Tri-sector antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 1.3 m (4 ft)
  • Width/Diameter: 354 – 457 mm
  • RF Connector Interface: 4.3-10 Female | M-LOC
  • RF Connector Quantity, total: 42
  • RF Connector Quantity, high band: 24
  • RF Connector Quantity, mid band: 12
  • RF Connector Quantity, low band: 6
SpecificationsSpecs
3X-KVVS4-65B-R12
  • Product Type: Tri-sector antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 1.3 m (4 ft)
  • Width/Diameter: 354 – 457 mm
  • RF Connector Interface: 4.3-10 Female | M-LOC
  • RF Connector Quantity, total: 42
  • RF Connector Quantity, high band: 24
  • RF Connector Quantity, mid band: 12
  • RF Connector Quantity, low band: 6
3X-KVVSS-65A-R9 3X-KVVSS-65A-R9
30-ports tri-sector antenna, 6x 617-960, 12x 1695-2690 and 12x 3300-4000 MHz, 65° HPBW, 9x RETs.
3X-KVVSS-65A-R9
  • Product Type: Tri-sector antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 1.3 m (4 ft)
  • Width/Diameter: 354 – 457 mm
  • RF Connector Interface: 4.3-10 Female | M-LOC
  • RF Connector Quantity, total: 30
  • RF Connector Quantity, high band: 12
  • RF Connector Quantity, mid band: 12
  • RF Connector Quantity, low band: 6
SpecificationsSpecs
3X-KVVSS-65A-R9
  • Product Type: Tri-sector antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 1.3 m (4 ft)
  • Width/Diameter: 354 – 457 mm
  • RF Connector Interface: 4.3-10 Female | M-LOC
  • RF Connector Quantity, total: 30
  • RF Connector Quantity, high band: 12
  • RF Connector Quantity, mid band: 12
  • RF Connector Quantity, low band: 6
3X-RRV4-65B-R12 3X-RRV4-65B-R12
36- ports tri-sector antenna ,12x 694-960 and 24x 1695-2690 MHz, 65° HPBW, 12x RET
3X-RRV4-65B-R12
  • Product Type: Tri-sector antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 2.0 m (6 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 36
  • RF Connector Quantity, mid band: 24
  • RF Connector Quantity, low band: 12
SpecificationsSpecs
3X-RRV4-65B-R12
  • Product Type: Tri-sector antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 2.0 m (6 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 36
  • RF Connector Quantity, mid band: 24
  • RF Connector Quantity, low band: 12
3X-RRZZHHTTS4-BR24 3X-RRZZHHTTS4-BR24
72-port sector antenna, 12x 694-960, 12x 1427-2690, 12x 1695-2180, 12x 2490-2690MHz 65° HPBW and 24x 3300-3800 MHz, 90° HPBW, 24x RET
3X-RRZZHHTTS4-BR24
  • Product Type: Sector antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 2.0 m (6 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 4.3-10 Female | M-LOC
  • RF Connector Quantity, total: 72
  • RF Connector Quantity, high band: 24
  • RF Connector Quantity, mid band: 36
  • RF Connector Quantity, low band: 12
SpecificationsSpecs
3X-RRZZHHTTS4-BR24
  • Product Type: Sector antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 2.0 m (6 ft)
  • Width/Diameter: > 499 mm
  • RF Connector Interface: 4.3-10 Female | M-LOC
  • RF Connector Quantity, total: 72
  • RF Connector Quantity, high band: 24
  • RF Connector Quantity, mid band: 36
  • RF Connector Quantity, low band: 12
3X-RVV-65A-R9 3X-RVV-65A-R9
18-port sector antenna, 6x694-960 and 12x1695–2690 MHz, 65° HPBW, 9xRET.
3X-RVV-65A-R9
  • Product Type: Tri-sector antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 1.3 m (4 ft)
  • Width/Diameter: 354 – 457 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 18
  • RF Connector Quantity, mid band: 12
  • RF Connector Quantity, low band: 6
SpecificationsSpecs
3X-RVV-65A-R9
  • Product Type: Tri-sector antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 1.3 m (4 ft)
  • Width/Diameter: 354 – 457 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 18
  • RF Connector Quantity, mid band: 12
  • RF Connector Quantity, low band: 6
3X-S4-90M-R3 3X-S4-90M-R3
24-port tri-sector Antenna, 3 planar arrays pointing 0-120-240 degrees, 3300–4000 MHz, 90° HPBW, 3x RET
3X-S4-90M-R3
  • Product Type: Tri-sector antenna
  • RF Connector Interface: M-LOC
  • RF Connector Quantity, total: 24
  • RF Connector Quantity, high band: 24
SpecificationsSpecs
3X-S4-90M-R3
  • Product Type: Tri-sector antenna
  • RF Connector Interface: M-LOC
  • RF Connector Quantity, total: 24
  • RF Connector Quantity, high band: 24
3X-V65A-3XR 3X-V65A-3XR
6-port tri-sector antenna, 6x 1710–2690 MHz, 65° HPBW, 3x RET.
3X-V65A-3XR
  • Product Type: Tri-sector antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 2.0 m (6 ft)
  • Width/Diameter: ≤ 200 mm
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 6
  • RF Connector Quantity, high band: 6
SpecificationsSpecs
3X-V65A-3XR
  • Product Type: Tri-sector antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 2.0 m (6 ft)
  • Width/Diameter: ≤ 200 mm
  • RF Connector Interface: 7-16 DIN Female
  • RF Connector Quantity, total: 6
  • RF Connector Quantity, high band: 6
FVV-65A-3XKIT FVV-65A-3XKIT
Tri-sector solution that includes 3 FVV-65A-R3-V1 antennas and mounting kit to install them on a pipe
FVV-65A-3XKIT
  • Product Type: Tri-sector antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 1.3 m (4 ft)
  • Width/Diameter: 201 – 305 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 18
  • RF Connector Quantity, mid band: 12
  • RF Connector Quantity, low band: 6
SpecificationsSpecs
FVV-65A-3XKIT
  • Product Type: Tri-sector antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 1.3 m (4 ft)
  • Width/Diameter: 201 – 305 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 18
  • RF Connector Quantity, mid band: 12
  • RF Connector Quantity, low band: 6
FVV-65B-3XKIT FVV-65B-3XKIT
Tri-sector solution that includes 3 FVV-65B-R3-V1 antennas and mounting kit to install them on a pipe
FVV-65B-3XKIT
  • Product Type: Tri-sector antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 2.0 m (6 ft)
  • Width/Diameter: 201 – 305 mm
  • RF Connector Quantity, total: 18
  • RF Connector Quantity, high band: 12
  • RF Connector Quantity, low band: 6
SpecificationsSpecs
FVV-65B-3XKIT
  • Product Type: Tri-sector antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 2.0 m (6 ft)
  • Width/Diameter: 201 – 305 mm
  • RF Connector Quantity, total: 18
  • RF Connector Quantity, high band: 12
  • RF Connector Quantity, low band: 6
KVVSS-65A-3XKIT KVVSS-65A-3XKIT
Tri-sector solution that includes 3 KVVSS-65A-R3-V1 antennas and mounting kit to install them on a pipe
KVVSS-65A-3XKIT
  • Product Type: Tri-sector antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 1.3 m (4 ft)
  • Width/Diameter: 201 – 305 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 30
  • RF Connector Quantity, high band: 12
  • RF Connector Quantity, mid band: 12
  • RF Connector Quantity, low band: 6
SpecificationsSpecs
KVVSS-65A-3XKIT
  • Product Type: Tri-sector antenna
  • Operating Frequency Band Range: 1427 – 2700 MHz | 3100 – 5000 MHz | 575 – 960 MHz
  • Horizontal Beamwidth: 65°
  • Length Size: 1.3 m (4 ft)
  • Width/Diameter: 201 – 305 mm
  • RF Connector Interface: 4.3-10 Female
  • RF Connector Quantity, total: 30
  • RF Connector Quantity, high band: 12
  • RF Connector Quantity, mid band: 12
  • RF Connector Quantity, low band: 6
Compare
BSA-FAQ-CO-117108-EN-500x281
Fact Sheet

New Tri-Sector Base Station Antenna from CommScope
